Epilog Fusion Edge Technical Specifications

Technical Specifications

  Fusion Edge 12 Fusion Edge 24 Fusion Edge 36
Work Area 24” x 12”
(610 x 305 mm)
24” x 24”
(610 x 610 mm)
36” x 24”
(914 x 610 mm)
Maximum Z-Depth 7” (178 mm) 10” (254 mm) 10” (254 mm)
Laser Tube Wattage CO2 - 30, 40, 50, or 60 watt
  • air-cooled, metal/ceramic tube, 10.6 micrometers
- OR -

Fiber - 30 watt
  • air-cooled, includes collimator, 1064 nm, Beam quality: M2 < 1.1
CO2 - 30, 40, 50, 60, or 80 watt
  • air-cooled, metal/ceramic tube, 10.6 micrometers
CO2 - 50, 60, or 80 watt
  • air-cooled, metal/ceramic tube, 10.6 micrometers
Software Epilog Laser Software Suite: Laser Dashboard™ & Epilog Job Manager™
Memory Multiple files, up to 1 GB total. Engrave any file size.
Operating Modes Optimized Raster, Vector, and Combined modes
Motion Control High-speed, continuous-loop, brushless DC servo motors using rotary encoding technology for precise positioning
X-Axis Bearings Ground & polished stainless steel, Teflon-coated, self-lubricating bearings.
Belts Advanced B-style double-wide Kevlar precision drive belts.
Resolution Fully-flexible and user-controlled from 75 – 1200 dpi
Optional Lenses 1.5" or 4.0"
Speed and Power 120 IPS (3.05m/s) with 5G acceleration. Computer-controlled in .001 increments up to 100%. Color mapping feature links Speed, Power, Frequency, and Raster/Vector mode.
Print Interface USB, Wireless, and 10Base-T Ethernet. Windows 7/8/10 compatible.
Size (W x D x H) 39.5” x 26.5” x 17.9"
1003 x 673 x 455 mm
41.52” x 32.81” x 38.04"
1055 x 834 x 967 mm
53.52” x 32.81” x 38.04"
1359 x 834 x 967 mm
Weight 138 lbs (63 kg) 225 lbs (102 kg) 260 lbs (117 kg)
Electrical 110 to 240 volts, 50 or 60 Hz, single phase
Ventilation 350-400 CFM (595-680 m3/hr) external exhaust to outside or internal filtration unit required. One output port, 4" (102 mm) diameter.
Safety Class 2 Laser Product – 1 mW CW MAXIMUM 600 – 700 nm
Technical specifications and product configurations subject to change without notice.
